8CH NVR W/ 4 8MP CAMERAS 4 CABLES
Camera Features
- 8 Megapixel (3840 x 2160) Resolution
- Fixed Lens
- H.265, H.264, MJPEG Compression
- True WDR
- 98’ IR Range
- IP Plug & PlayTrue Plug & Play With Ultra, Paramont & Vision
- IP66 Weatherproof
- Withstand up to -40F Operation
- IK10 Vandal Resistant
- ONVIF
- 12VDC/PoE Operation
- Free Central Management Software (CMS) to manage multiple units & sites from a single platform through the NVR
- Free iOS & Android Apps for Smart Phones &Tablets
- Free Mac Client
NVR Features
- 8 Channel with 8 Plug & Play Ports for easy camera setup PoE (Power Over Ethernet) available on all ports
- Up to 8 Megapixel Resolution Recording
- 80 Mbs Bit Rate Input
- Works with ONVIF or other supported IP cameras
- Local HDMI main monitor output with 4K Support
- Local VGA main monitor output up to 1080p
- H.265/H.265 /H.264/H.264 video compression
- Free Central Management Software (CMS)
Camera Image Sensor 1/2.8” Progressive Scan CMOS Effective Pixels 3840(H)×2160(V) Electronic Shutter Auto/Manual, 1/5 ~ 1/20,000s Min. illumination Color: 0.05 Lux @ (F1.2, AGC ON) , B/W: 0 Lux @ (IR LED ON) S/N Ratio 55dB Day/Night Auto(ICR) True WDR Support IR Range Up to 98 ft (30 m) IR On/Off Control Auto/Manual Pan/Tilt/Rotation Range Pan: 0˚ ~ 350˚, Tilt: 0˚ ~ 75˚, Rotation: ±90˚ Lens Lens Type Fixed Focus Iris Fixed Iris Focal Length 2.8 mm F Number F2.0 Angle of View H: 102°, V: 55.6° Focus Control Fixed Video Compression H.265/H.264/MJPEG Max. Resolution 8MP (3840×2160) Streaming Capability 3 Streams Stream/Frame Rate Stream1: 3840×2160, 3072×2048, 2592×1520, 1920×1080 @ 20fps
Stream2: D1, VGA, CIF, QVGA @ 25/30fps
Stream3: VGA, CIF, QVGA @ 25/30fpsBit Rate Control CBR/VBR Bit Rate Stream1: 500kbps~16Mbps Stream2: 10kbps~6Mbps Stream3: 10kbps~3Mbps Image Enhancement HLC / BLC / Anti-shake / WDR White Balance Support Gain Control Auto/Manual Noise Reduction 2D/3D DNR Smart IR Support Mirror Support Region of Interest Support Motion Detection Support Privacy Masking Support Network Protocols IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP, TLS/SSL Interoperability ONVIF Profile S/G/Q/T, SDK, CGI Streaming Method Unicast Max. User Access 10 Users Web Viewer Management Software InVid View Interface Ethernet 1 Ethernet (10/100 Base-T) RJ-45 Connector Reset Button Support Storage Built-in Micro SD slot, up to 256G Electrical Power Supply DC12V/POE (IEEE 802.3af) Power Consumption Max 5.5W Operating Temperature -40°F ~ 131°F (-40°C ~ 55°C ) Operating Humidity Less than 90% RH Ingress Protection IP67, IK10 Certifications CE/FCC Casing Metal Dimensions φ4.33” × 3.36” (φ110 × 85.4mm) Net Weight .93 lb (0.42 kg)
System
Main Processor
Dual-core embedded processor
Operating System
Embedded LINUX
Video and Audio
IP Camera Input
8 Channel
Audio I/O
1/1, RCA
Two-way Talk
Yes
Display
Interface
1 HDMI, 1 VGA
Resolution
HDMI: 3840×2160,1920×1080,1440×900, 1280×1024, VGA: 1920×1080, 1280×1024, 1280×720
Decoding Capacity
1ch 8MP/4ch 1080P@30fps
Multi-screen Display
1/4/09
Recording
Compression
H.265 / H.265/H.264 /H.264
Resolution
8MP/6MP/5MP/4MP/3MP/1080P/720P/ D1&etc.
Record Rate
80Mbps
Bit Rate
100Kbps ~ 6Mbps Per Channel
Record Mode
Manual, Schedule (Regular, Continuous), Motion Detection, Video Loss, Camera Tamper, Alarm in
Record Interval
Post-record: 30 ~ 60 sec
Video Detection and Alarm
Trigger Events
Recording, Buzzer, Push message, Pop up message.
Video Detection
Motion Detection, Video Loss, Camera Tamper
Alarm In/Out
8/1
Playback and Backup
Sync Playback
8/4/01
Search Mode
Time /Date, Alarm, Picture grid, Event
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom
Backup Mode
USB Device
Network
Network Function
HTTP, HTTPS, TCP/IP, IPv4, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP
Max. User
Access 9 users
Smart Phone
iPhone, iPad, Android
Interoperability
ONVIF, SDK, CGI
Storage
Internal HDD
2 SATA Ports, up to 8TB for each HDD
eSATA
N/A
Interface
Interface
1 RJ-45 port (10/100Mbps)
PoE Interface
8ch 100Mbps, IEEE 802.3af
PoE Max Power
80W
USB
2 ports (USB 2.0 x2)
General
Power Supply
DC48V/2.5A
Power Consumption
< 5W (without HDD)
Operating Conditions
14 °F ~ 122 °F (-10 °C ~ 50 °C)
Storage Conditions
Less than 90% RH
Certifications
CE/FCC
Dimensions
14.64” x 12.22” x 1.83” (372×310.5×46.5mm)
Net Weight
4.62lb (2.1kg) No disk
